The KT38-G is a 38L 12-cylinder engine with turbocharged and aftercooled aspiration. It offers continuous rating, delivering 560 kW of genset power-ideal for industrial plants, data centers, and emergency backup.
As a Cummins Authorized Dealer, we deliver the KT38-G engine-built for demanding applications-with sales, service, and support that meet Cummins' strict standards.
Technical Parameter Table
|
Parameter |
Value |
|
Engine Model |
KT38-G |
|
Cylinder Configuration |
12-cylinder V-type |
|
Displacement |
38 L (38 liters) |
|
Rated Power |
560 kW (750 HP) @ 1500 rpm |
|
Bore x Stroke |
159 x 159 mm (6.25 x 6.25 in) |
|
Fuel System |
PT Pump Direct Injection |
|
Aspiration |
Turbocharged-Aftercooled |
|
Net Weight (Dry) |
3609 kg (7950 lbs) |
|
Net Weight (Wet) |
3832 kg (8448 lbs) |
|
Compression Ratio |
15.5:1 |
|
Emission Standard |
Non-Regulated |
Durable Design
Cummins engineers the KT38-G for longevity: 4 valves per cylinder boost efficiency and emissions performance, while the alloy cast iron cylinder head adds reliability. A balanced crankshaft reduces wear, and steel piston crowns lower oil consumption.
Reliable Systems
The KT38-G's lubrication system uses a high-flux pump and filters to trap impurities above 10um, protecting parts. Its cooling system has a powerful water pump and spin-in filter to prevent overheating.
Its exhaust system integrates Holset turbochargers and a pulse manifold, lowering temperatures to improve efficiency and meet emission standards.
Choose us for expert advice, installation, and maintenance-trust Cummins quality and our authorized support.
Why Choose Us
Full Range of Genuine Cummins
Huge inventory(Engines & Parts)
