The Diesel Generator Set, powered by the Cummins KT38-G engine, delivers reliable, efficient, and high-performance power for industrial, commercial, and data center applications. Designed for continuous operation, it ensures stable power output and long-term durability even under harsh working conditions.
|
General data of Cummins KT38-G Diesel Engine for Generator Set |
|||
|
Engine Model |
Cummins KT38-G |
||
|
Type |
4 Stroke; 60° Vee; 12-Cylinder Diesel |
||
|
Displacement |
38 L |
||
|
Bore&Stroke |
159*159 mm |
||
|
Dry Weight(fan to flywheel engine) |
3609 KG |
||
|
Wet Weight(fan to flywheel engine) |
3832 KG |
||
|
Center of Gravity from Rear Face of Flywheel Housing |
980 mm |
||
|
Center of Gravity Above Crankshaft Centerline |
279 mm |
||
|
Performance Date of Cummins KT38-G Diesel Engine for Generator Set |
|||
|
Rated Output/Speed |
560KW/750HP/1500RPM |
||
|
Standby Output/Speed |
615KW/825HP/1500RPM |
||
|
Continuous Output/Speed |
|
||
|
Brake Mean Effective Pressure(rated output) |
|
||
|
Brake Mean Effective Pressure(standby output) |
2330 KPa |
||
|
Fuel Consumption/Rated Output |
140 L/h |
||
|
Fuel Consumption/Standby output |
154 L/h |
||
|
Technical data of Cummins KT38-G Diesel Engine for Generator Set |
|||
|
Aspiration |
Turbocharged |
||
|
Fuel System |
PT Pump Direct Injection |
||
|
Coolant capacity-engine only |
111 L |
||
|
Oil Pan Capacity-Low/High |
87/114 L |
||
|
Idle speed |
725-775 RPM |
||
|
Frictional loss power/rated output |
86 KW |
||
|
Compression ratio |
15.5:1 |
||
|
Piston Speed |
7.9 m/sec |
||
Advantages of diesel generator sets
1. High Power and Stability – Delivers 680 kW continuous output with strong torque and consistent performance for heavy-duty applications.
2. Fuel Efficient – Advanced Cummins PT fuel system and turbocharging ensure complete combustion, lowering fuel use and operating costs.
3. Reliable and Durable – Rigid alloy cast-iron design, 4-valve system, and tested crankshaft ensure long life, low vibration, and dependable performance in harsh conditions.
4. Efficient Cooling & Easy Maintenance – Optimized cooling system and accessible components simplify upkeep and reduce downtime.
5. Smart Control & Versatility – AVR and Power Command system provide precise voltage/frequency control, remote monitoring, and adaptability to various environments.
Why Choose Us
Full Range of Genuine Cummins
Huge inventory(Engines & Parts)
FAQ
Q1: What is the packaging method?
A1: The generator set is securely packed in wooden cases for safe transportation.
Q2: How is it shipped?
A2: Shipping options include delivery by sea or by rail, depending on customer requirements and destination.
Q3: What payment methods are available?
A3: We accept T/T (Telegraphic Transfer) and L/C (Letter of Credit) payments.
Q4: What is the minimum order quantity (MOQ)?
A4: The minimum order quantity is one unit.
Q5: What about after-sales service?
A5: We provide comprehensive after-sales support, including installation guidance, technical training, spare parts supply, and 24/7 customer service.
Q6: How long is the production and delivery time?
A6: Standard production and delivery time is typically 20–30 days after order confirmation, depending on order quantity and customization requirements.
