This 224KW home generator delivers stable, high-power output for daily household use and emergencies. Its silent design, compact structure, and Cummins MTA11-G2 engine ensure dependable operation with minimal maintenance.
|
General data of Cummins MTA11-G2 Diesel Engine for Generator Set |
|
|
Engine Model |
Cummins MTA11-G2 |
|
Type |
6 Cylinder, In-line, 4 Stroke |
|
Displacement |
11 L |
|
Bore&Stroke |
125*147 mm |
|
Dry Weight(include flywheel and generator) |
940 KG |
|
Wet Weight(include flywheel and generator) |
980 KG |
|
Center of Gravity from Rear Face of Flywheel Housing |
450 mm |
|
Center of Gravity Above Crankshaft Centerline |
191 mm |
|
|
|
|
Performance Date of Cummins MTA11-G2 Diesel Engine for Generator Set |
|
|
Rated Output/Speed |
224KW/1500RPM |
|
Standby Output/Speed |
246KW/1500RPM |
|
Brake Mean Effective/Rated Output |
1651 KPa |
|
Brake Mean Effective/Standby Output |
1816 KPa |
|
Fuel Consumption/Rated Output |
59 L/h |
|
Fuel Consumption/Standby output |
57 L/h |
|
|
|
|
Technical data of Cummins MTA11-G2 Diesel Engine for Generator Set |
|
|
Aspiration |
Turbocharged, Aftercooled |
|
Fuel System |
PT Pump Direct Injection |
|
Engine Coolant Flow |
3.8 L/s |
|
Coolant Capacity, Engine Only |
12.9 L |
|
Oil Pan Capacity-High/Low |
34/30 L |
|
Idle speed |
675-750 RPM |
|
Minimum Engine Speed |
500 RPM |
|
Maximum Governed Speed |
1725 RPM |
|
Maximum Over Speed Capability |
1725 RPM |
|
Compression ratio |
16.1:1 |
|
Piston Speed |
7.4 m/sec |
|
Maximum Friction Power |
22.4 KW |
Advantages of silent diesel generators:
●Low Noise Operation: Fully enclosed sound-insulated cover keeps noise below 75dB at 1 meter, ensuring quiet operation in residential areas.
●Stable & Compatible Power Supply: Rated 200KW at 50Hz, safely powers high-demand appliances like central air conditioners, water heaters, and electric stoves, as well as sensitive electronics, without voltage fluctuations.
●Durable & Efficient Engine: Cummins engine offers over 10,000 hours of service life, low fuel consumption (210–230g/kWh), and minimal maintenance.
●User-Friendly & Safe: Simple control panel with clear indicators; built-in protections against overload, overheating, low oil pressure, and short circuits.
●Flexible & Long-Term Use: Runs 8–12 hours per full tank depending on load; compact design fits yards, garages, or small machine rooms.
Factory Advantages
Custom manufacturing to meet specific power and design requirements.
Authorized Cummins partner with extensive OEM experience.
Complete after-sales support, including spare parts availability and responsive technical service.
FAQ for Buyers
Packaging: Wooden packing for secure transport.
Shipping: By sea or rail.
Payment Terms: TT or LC.
Minimum Order Quantity: One unit.
After-Sales Service: Installation guidance, maintenance, and technical support provided.
