The Cummins KTA19-G3A 600KVA silent diesel generator provides stable, high-power output for industrial, commercial, and critical applications. Its silent operation, fuel-efficient engine, and robust design ensure reliable performance in demanding environments.
|
GENERAL INFORMATION – Cummins KTA19-G3A 448kW |
||
|
Engine Model |
Cummins KTA19-G3A 448kW |
|
|
Engine Type |
6 Cylinders, in Line |
|
|
Displacement |
18.9 L |
|
|
Bore * Stroke |
159 * 159 |
|
|
Net Weight |
1760 Kg |
|
|
Overall Dimension |
1324mm*835mm*1183m |
|
|
Manufacture Plant |
Chongqing Cummins Plant |
|
|
PERFORMANCE DATA – Cummins KTA19-G3A 448kW |
||
|
Prime Power |
448 kW/600 HP @1500rpm |
|
|
Standby Power |
504 kW/675 HP @1500rpm |
|
|
Torque |
N. A |
|
|
Idle Speed |
@675-775RPM |
|
|
Fuel Consumption |
90.95 L/Kw. h |
|
|
TECHNICAL SPECIFICATION – Cummins KTA19-G3A 448kW |
||
|
Aspiration |
Turbocharged & Aftercooled |
|
|
Fuel System |
Cummins PT Pump, Direct Injection |
|
|
Governor Type |
Mechanical Control |
|
|
Compression Ratio |
13.9:1 |
|
|
Electrical System (Starter Motor/Alternator) |
24V |
|
|
Lowest Starting Temp Without auxiliary system |
-12℃ |
|
|
Engine Exhaust Manifold |
Optional for Wet Exhaust manifold Heat exchanger |
|
|
Cooling Method |
Water Cooled |
|
|
Gensets Specifications |
||
|
Standby Output |
550kVA |
|
|
Prime Power |
500kVA |
|
|
Voltage |
400/230V |
|
|
Frequency |
50Hz |
|
|
Current |
721.7A |
|
|
Fuel Type |
Diesel Fuel |
|
|
Cooling Methon |
Water Cooling |
|
|
Engine Brand |
Cummins |
|
|
Engine Model |
KTA19-G3A |
|
|
Alternator Brand |
Stamford |
|
|
Alternator Model |
HCI 544 C |
|
|
Fuel Tank |
600Litres |
|
|
Fuel Consumption |
91 Litres Per Hour At 100% Load |
|
|
Noise Level |
78dBA At 7 Meters |
|
|
Highlight |
500kVA cummins diesel generator |
|
The Features and Advantages of Cummins KTA19-G3A Engine 600KVA 500kW Silent Diesel Generator
Stable & Reliable Power Supply: 6-cylinder inline, turbocharged and aftercooled engine with 18.9L displacement. Equipped with Automatic Voltage Regulator (AVR), it maintains voltage within ±0.5% and frequency within ±2% from no-load to full load, ideal for data centers, hospitals, and sensitive equipment.
High Fuel Efficiency: Patented PT fuel system combined with Holset turbocharger and air-to-air intercooling ensures full combustion, reduces fuel consumption, and lowers operating costs-suitable for factories and long-term continuous operations.
Low Noise & Environmental Adaptability: Silent-type design with advanced sound reduction keeps noise below 78 dBA at 7 meters. Compact, weather-resistant enclosure supports indoor/outdoor use in urban, residential, and commercial areas.
Easy Operation & Maintenance: Digital control panel displays voltage, current, and frequency. Replaceable wet cylinder liners and composite oil filters reduce downtime and maintenance costs.
Strong Load-Bearing Capacity: Large displacement and high power enable rapid response to load changes and handle sudden load spikes, suitable for industrial production lines, mining, and other high-demand applications.
FAQ for Buyers
Packaging: Wooden packing for safe transport.
Shipping: By sea or rail.
Payment: TT or LC.
Minimum Order: One unit.
Operation & Maintenance: User-friendly control panel and highly serviceable parts ensure hassle-free monitoring and maintenance.
Applications: Ideal for factories, construction sites, hospitals, data centers, commercial centers, and other areas requiring stable, high-capacity power.
