The KTA50-G3 diesel generator adopts a 16-cylinder V-type Cummins engine with a 50-liter displacement, providing a prime power output of around 1097kW and a standby power of approximately 1227kW. It is ideal for mid-to-large-scale facilities such as manufacturing plants, commercial centers, and regional power stations, ensuring stable backup power during main grid interruptions.
|
General data of Cummins KTA50-G3 Diesel Engine for Generator Set |
|
|
Engine Model |
Cummins KTA50-G3 |
|
Type |
4 Stroke; 60° Vee; 16-Cylinder Diesel |
|
Displacement |
50 L |
|
Bore&Stroke |
159*159 mm |
|
Dry Weight (engine only) |
4858 KG |
|
Wet Weight (engine only) |
5160 KG |
|
Center of Gravity from Rear Face of Flywheel Housing |
1206 mm |
|
Center of Gravity Above Crankshaft Centerline |
279 mm |
|
|
|
|
Performance Date of Cummins KTA50-G3 Diesel Engine for Generator Set |
|
|
Rated Output/Speed |
1097KW/1470HP/1500RPM |
|
Standby Output/Speed |
1227KW/1645HP/1500RPM |
|
Continuous Output/Speed |
|
|
Brake Mean Effective Pressure(rated output) |
1744 KPa |
|
Brake Mean Effective Pressure(standby output) |
1951 KPa |
|
Fuel Consumption/Rated Output |
254 L/h |
|
Fuel Consumption/Standby output |
282 L/h |
|
|
|
|
Technical data of Cummins KTA50-G3 Diesel Engine for Generator Set |
|
|
Aspiration |
Turbocharged Aftercooled |
|
Fuel System |
PT Pump Direct Injection |
|
Coolant capacity-engine only |
161 L |
|
Oil Pan Capacity-Low/High |
121/151 L |
|
Idle speed |
725-775 RPM |
|
Frictional loss power/rated output |
116 KW |
|
Compression ratio |
13.9:1 |
|
Piston Speed |
7.9 m/sec |
Advantages of KTA50-G3 Generator Sets
Efficient Fuel Control – Cummins PT fuel system automatically adjusts fuel injection based on load, lowering fuel consumption and improving long-term operating efficiency.
Reliable Cooling & Filtration – High-efficiency air filters and a large-capacity water-cooling system ensure stable performance in dusty or high-temperature environments.
Stable Power Output – Electronic governor maintains frequency (50/60Hz) and voltage stability within ±1%, protecting sensitive equipment from power fluctuations.
Easy Maintenance – Accessible filter layout and simplified lubrication inspection reduce downtime, allowing quick and convenient servicing.
Why Choose Us
Full Range of Genuine Cummins
Huge inventory(Engines & Parts)
FAQ
Q1: What type of packaging is used?
A1: The generator is packed in sturdy wooden cases to ensure safe transportation.
Q2: How is the product shipped?
A2: Shipping is available by sea or by rail, depending on the customer's preference and destination.
Q3: What payment methods are supported?
A3: We accept T/T (Telegraphic Transfer) and L/C (Letter of Credit).
Q4: What is the minimum order quantity (MOQ)?
A4: The minimum order quantity is one unit.
Q5: How long is the production or delivery time?
A5: Standard production and delivery typically take 25–35 days after order confirmation and payment arrangement.
Q6: What about after-sales service?
A6: We provide a one-year warranty. Technical support and spare parts are available throughout the product's service life.
